Product Name:

DANNOVO Hitachi 20x Zoom Full HD 1080P PTZ IP High Speed Dome Camera,2.0 Megapixel,Support Micro SD Card,Two-Way Audio,RTSP,Onvif Protocol,iPhone,Android Compatible(DN-HDPTZ03H-MPC-TS)

Main Features

DANNOVO Hitachi 20x Zoom Full HD 1080P PTZ IP High Speed Dome Camera DN-HDPTZ03H-MPC-TS,2.0 Megapixel,Support Micro SD Card,Two-Way Audio,RTSP,Onvif Protocol,iPhone,Android Compatible:


Hitachi 20x Zoom Full HD 1080P PTZ IP High Speed Dome Camera Features:

1/2.8" Progressive Scan CMOS Sensor ,Total pixels :2.1 Megapixel, Hitachi 20x Optical Zoom,Horizontal Rotation Range:360 degree;Vertical:90 degree;Horizontal Speed:0-300degree/sec,Vertical:0-120 degree/sec, Min.Illumination: Color Mode:0.1Lux@F1.6,B/W Mode:0.01Lux@F1.6,Video Compression:H.264 Main Profile,Dual Stream,Onvif Protocol,Mobile Phone,Max.Resolution:1920x1080,Dual IR-Cut filter,High-strength aluminum shell,Water and Dust Resistance:IP66.
>1/2.8"Progressive Scan CMOS Sensor, Total pixels:2.1 MegaPixels;
> Hitachi 20x Optical Zoom;
> Min. Illumination: Color Mode:0.1Lux@F1.6,B/W Mode:0.01Lux@F1.6;
> Focal Length: f=4.7mm (W)-94mm (T);
> Horizontal Angle of View: 55.2° (W)~2.9°(T);
> Support Micro SDHC Card for Storage;
> Max Resolution:1920x1080, output Real-time Full HD 1080P Image;
> Horizontal Range:360°Continuous Rotation, Vertical Range:90°;
> Horizontal Speed:0~300º/S, Vertical Speed:0~120º/S;
> Dual IR-Cut filter for Day/Night Switching;
> Dual-streaming:H.264 and MJPEG;
> Preset Positions: 256,Precision±0.1°;
> Aluminum Shell,IP66 Outdoor waterproof;
> Support Two-way Audio,Motion Detection,Alarm;
> Onvif Compliant;
> Support BNC Output,OSD Menu;
> Mobile Phone Viewing: iPhone, Android, Symbian and Windows Mobile;
> H.264 Main Profile@Level 3, realize transmission of High Definition video over low network bandwidth easily;
>Auto Scan,Horizontal /Vertical rotation range angle can be set,scanning speed adjustable;
>Patrol:2 groups, each patrol up to 8 presets;
>Timed task:5 groups; Preset / Pattern / Patrol / Rotate/ Auto Scan Resume Function;
> Upto 10viewers can directly access the camera simultaneously;
> Built-in Web server enables the use of a standard Web browser for viewing and management;
> Support remote control and view ip camera;
> Support remote software upgrade;
> Support dynamic IP address , LAN, Internet (ADSL and Cable Modem);
> Auto-adjusting frame rate according to realtime network rate;
> Alarm recording: video lost, motion detection and sensor alarm;
> Auto-recovery after exception occurs or the network being reconnect.


Optional Models:


Camera Module Sony Hitachi
Sensor 1/2.8" Sony Exmor CMOS 1/2.8"Progressive Scan CMOS
Effective Pixels 3.27 Mega Pixels 2.1 Mega Pixels
Effective Highest Resolution 1920(H)×1080(V)
Lens Sony 20x Optical X 12x Digital Zoom Hitachi 20x Optical Zoom
Min.Illumination Color Mode:0.5Lux@F1.6,B/W Mode:0.095Lux@F1.6,WDR Color Mode:0.1Lux@F1.6,B/W Mode:0.01Lux@F1.6


Applications Scenarios:

Applicable to forests, scenic, highway, railway, airport, port, square, park, street, railway stations, stadiums, residential district and other places.

  Hitachi 20x Zoom Full HD 1080P PTZ IP High Speed Dome Camera Specifications Hitachi 20x Zoom Full HD 1080P PTZ IP High Speed Dome Camera Details Hitachi 20x Zoom Full HD 1080P PTZ IP High Speed Dome Camera Download

Hitachi 20x Zoom 1080P PTZ IP High Speed Dome Camera Model

Network chip Lan Realtek 10/100M BASE-TX Self-adapting
Sensor 1/2.8"Progressive Scan CMOS
Effective Pixels 1920(H)×1080(V),2.1MegaPixel
Lens Hitachi 20x Optical Zoom
Focal Length f=4.7mm(W) ~ 94mm(T)
Iris F1.6 ~F3.5
Horizontal Angle of View 55.2°(W)~2.9°(T)
Min.Illumination Color Mode:0.1Lux@F1.6,B/W Mode:0.01Lux@F1.6

Auto (Dual IR-Cut filter)

S/N ≥50db(AGC OFF)
Parameters adjustment AWB,AGC,BLC
Auto Electronic Shutter 1/25—1/10000sec,Slow shutter:1/2,1/4,1/8,1/12sec
Audio Talkback 1 channel MIC input,3.5mm connector
Audio Output 1 channel Output,3.5mm connector
Video Output 1 channel BNC Output
Network Interface Lan 10/100M BASE-TX,RJ-45 connector
I/O 1-channel input, Normally Open/Normally Close modes adjustable; 1-channel output, 120VAC 1A/24VDC 1A
Storage Interface Micro SD card supports video storage and image snapping;
SD2.0 standard, maximum storage 32G
Audio video encoding
Video Compression H.264 Main Profile,MJPEG/JPEG Baseline
Resolution Master Streaming 1920x1080,1-25(30)fps/sec
Second Streaming 640*480,1-25fps/sec320*240,1-25fps/sec160*112,1-25fps/sec
Video Bitrate 32Kbps~16Mbps,Supports CBR/VBR
Title OSD Supports channel name, date, and video stream information overlay; OSD location is adjustable
Audio Compression G.726,G7.11A,G.711U,AAC,Support 32 K Stereo
Data transmission and storage
Data storage Video and Image
Recording Manual
Alarm Output E-mail, Explorer, Software
ONVIF protocol Support
Remote View Computer IE 6.0 or up, max 16 user
Mobile Phone Support Windows Mobile, Symbian, iPhone, Android platform
General Parameters
OSD Menu Support
Water and Dust Resistance IP66
Mechanical properties Horizontal Range 360°Continuous Rotation
Horizontal Speed 0°~300°/s
Vertical range 0°~90°(Auto flip)
Vertical speed 0°~120°/s
Preset speed 400°/s
Preset precision ±0.10°
Proportional Zoom Support
Preset positions 256
Patrol 2 patrols, up to 8 presets per patrol
Pattern 2 patterns
Power-off Memory Support
Park Action Preset / Pattern / Patrol / Pan Tilt scan /Auto
PTZ Display Support
Timed task 5-channel periodic launches :Preset / Pattern / Patrol / Pan Tilt scan /Auto
Material All Aluminum Crust
Operating Temperature -30℃-+60℃
Operating Humidity 0% - 90%
Power 24V AC,2A
Power Consumption 35W
