Product Name:
DANNOVO Outdoor PTZ High Speed Dome Camera,China 23x,30x,27x,37x,18x Optical Zoom,360º Rotation(DN-CPTZ061H)
Main Features
DANNOVO Outdoor PTZ High Speed Dome Camera,China 23x,30x,27x,37x,18x Optical Zoom,360º Rotation(DN-CPTZ061H):
Outdoor PTZ High Speed Dome Camera Features:
>Horizontal Rotation Range:360º,Horizontal Rotation Speed: 200°/s;Tilt Rotation Range:93º,Tilt Rotation Speed: 100°/s;
>Optional Cameras: Dannovo,Samsung,Sony,CNB,LG,Hitachi;
>Time Scheduling Function;
>Dome ID, Baud Rate, Communication Protocol Can Be Set Via The Controller;
>Supported Protocols: Pelco-D/P; Others On Special Request;
>7" Total Metal Body Construction, Waterproof IP66;
>Preset Points:220;Go To Preset Speed:01-64 Grades Selectable.
>4 Alarm Inputs and 2 Alarm Outputs Optional.
 |
 |
 |
|
 |
|||
| Optional Model NO. | Description | ||
| Dannovo 23x Zoom | 1/3" CCD, IR-CUT,EFFIO, 650TVLine,23x Optical Zoom | ||
| Dannovo 30x Zoom | 1/4" CCD, IR-CUT,EFFIO 4140+649, 650TVLine,30x Optical Zoom | ||
| Sony 18x Zoom | Sony FCB Ex-480cp, 18x Optical Zoom, D/N,1/4 type IT EX-VIEW HAD CCD 18X D/N f = 4.1 (WIDE) to 73.8 (TELE) mm, 550TVline | ||
| Samsung 27x Zoom | Samsung SCM-2271P,27x Optical Zoom D/N,1/4 inch, Super HAD color CCD 27X, f=3.5 to 94.5mm(F 1.6 to 2.9) ,560 TV Lines(Min.) : Color / 680 TV Lines(Min.) : B/W | ||
| Samsung 37x Zoom | Samsung SCM-3371P 37x Optical Zoom D/N/WDR,1/4 inch, Double density interline treneter CCD37X, f=3.5 to 129.5mm(F 1.6 to 3.9) 550 TV Lines(Min.) : Color / 680 TV Lines(Min.) : B/W |
Specifications
| Model No. | DN-CPTZ061H |
| Horizontal Rotation Speed | 200°/s |
| Horizontal Rotation Range | 360° |
| Tilt Rotation Speed | 100º/s |
| Tilt Rotation Range | 93° |
| Auto Flip | Horizontal 180°,Vertical 180° |
| A-B Scan | User Programmable |
| A-B Scan Speed | 01-64 Level Setting Available |
| Dwell Preset | 01-60s Interval |
| Preset Points | 220 |
| Go To Preset Speed | 01-64 Level Setting Available |
| Guard Tours | 4 Groups |
| Guard Points | Max.16 Points, Dwell Time User Selectable |
| Park Time | 1-60mins Available |
| Communication Protocol | Pelco-D,Pelco-P |
| Communication | RS485 |
| Baud Rate | 1200/2400/4800/9600bps |
| Privacy Mask | 8-24pcs (According To Zoom Module Type) |
| Operating Temperature | -40°- +60° |
| Operating Humidity | ≤95% Non Condensing |
| Auto Temperature Control | |
| Power | AC/DC15-28V ≤2A |
| Lightning Protection | Transient Voltage 6000V |
| Compatible Camara | China Dannovo,Samsung,Sony,CNB,LG,Hitachi |
