Product Name:

DANNOVO Variable Illuminant IR 120M Medium Speed Dome Outdoor PTZ Camera,18x,23x,37x,Samsung 27x Optical Zoom(DN-CPTZ069VIM)

DANNOVO Variable Illuminant IR 120M Medium Speed Dome Outdoor PTZ Camera,18x,23x,37x,Samsung 27x Optical Zoom(DN-CPTZ069VIM)
Inquire:Variable Illuminant IR 120M Medium Speed Dome Outdoor PTZ Camera,18x,23x,37x,Samsung 27x Optical Zoom

Main Features

DANNOVO Variable Illuminant IR 120M Medium Speed Dome Outdoor PTZ Camera,18x,23x,37x,Samsung 27x Optical Zoom(DN-CPTZ069VIM):



Variable Illuminant IR Medium Speed Dome Camera Features:



>Variable Illuminant: IR Illumination Angle Variable From 5 Degrees To 60 Degrees;
>Medium Speed Dome PTZ Camera:Horizontal Rotation Range:360º,Horizontal Rotation Speed:100°/s;Tilt Rotation Range:93º,Tilt Rotation Speed:50°/s;
>Optional Cameras: Dannovo,Samsung,Sony,CNB,LG,Hitachi;
>PWM Function,Intelligent IR Illumination & Power Consumption Is Variable,Dependant Zoom Factor;
>IR Distance:120M; Multiple Languages For OSD Menu, English, Spanish Etc;
>Support Ambient Light Detection, IR Illumination On 1-15 Grades Selectable;
>Dome ID, Baud Rate, Communication Protocol Can Be Set Via The Controller;
>Supported Protocols: Pelco-D/P; Others On Special Request;
>7" Double Layers And Total Metal Body Construction, Waterproof IP66;
>Preset Points:220;Go To Preset Speed:01-64 Grades Selectable.
>4 Alarm Inputs and 2 Alarm Outputs Optional.

  Variable Illuminant IR 120M Medium Speed Dome Outdoor PTZ Camera,18x,23x,37x,Samsung 27x Optical Zoom Specifications Variable Illuminant IR 120M Medium Speed Dome Outdoor PTZ Camera,18x,23x,37x,Samsung 27x Optical Zoom Details Variable Illuminant IR 120M Medium Speed Dome Outdoor PTZ Camera,18x,23x,37x,Samsung 27x Optical Zoom Download
Optional Model NO. Description
Dannovo 23x Zoom 1/3" CCD, IR-CUT,EFFIO, 650TVLine,23x Optical Zoom
Sony 18x Zoom Sony FCB Ex-480cp, 18x Optical Zoom, D/N,1/4 type IT EX-VIEW HAD CCD 18X D/N f = 4.1 (WIDE) to 73.8 (TELE) mm, 550TVline
Samsung 27x Zoom Samsung SCM-2271P,27x Optical Zoom D/N,1/4 inch, Super HAD color CCD 27X, f=3.5 to 94.5mm(F 1.6 to 2.9) ,560 TV Lines(Min.) : Color / 680 TV Lines(Min.) : B/W
Samsung 37x Zoom Samsung SCM-3371P 37x Optical Zoom D/N/WDR,1/4 inch, Double density interline treneter CCD37X, f=3.5 to 129.5mm(F 1.6 to 3.9) 550 TV Lines(Min.) : Color / 680 TV Lines(Min.) : B/W



Specifications



Model No. DN-CPTZ069VIM
Horizontal Rotation Speed 100°/s
Horizontal Rotation Range 360°
Tilt Rotation Speed 50º/s
Tilt Rotation Range 93°
Auto Flip Horizontal 180°, Vertical 180°
Auto Control IR LED PWM
A-B Scan User Programmable
A-B Scan Speed 01-64 Level Setting Available
Dwell Preset 01-60s Interval
Preset Points 220
Go To Preset Speed 01-64 Level Setting Available
Guard Tours 3 Groups
Guard Points Max.16 Points, Dwell Time User Selectable
Park Time 1-60mins Available
PWR On Action Memory/No Action/A-B Scan/360° Scan/Home/Tour 1-3
Park Mode Off/A-B Scan/360° Scan/Home/Tour 1-3
Communication Protocol Pelco-D, Pelco-P
Communication RS485
Baud Rate 1200/2400/4800/9600bps
Operating Temperature  -40°- +60°
Operating Humidity ≤95% Non Condensing
Heater & Blower Auto Temperature Control
Power  AC/DC15-28V ≤3A
IR Illumination Distance 120M
Power Consumption ≤ 20W
Lightning Protection Transient Voltage 6000V
Compatible Camera China Dannovo,Samsung,Sony,CNB,LG,Hitachi
LED Angle Of Illumination 5-60 °
